Starters for Forklift
Forklift Starters - The starter motor these days is usually either a series-parallel wound direct current electric motor which includes a starter solenoid, that is similar to a relay mounted on it, or it can be a permanent-magnet composition. As soon as current from the starting battery is applied to the solenoid, basically via a key-operated switch, the solenoid engages a lever which pushes out the drive pinion that is positioned on the driveshaft and meshes the pinion using the starter ring gear which is found on the flywheel of the engine.
Once the starter motor begins to turn, the solenoid closes the high-current contacts. As soon as the engine has started, the solenoid has a key operated switch that opens the spring assembly in order to pull the pinion gear away from the ring gear. This particular action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by an overrunning clutch. This permits the pinion to transmit drive in only one direction. Drive is transmitted in this manner via the pinion to the flywheel ring gear. The pinion remains engaged, like for example as the driver did not release the key as soon as the engine starts or if there is a short and the solenoid remains engaged. This causes the pinion to spin independently of its driveshaft.
This aforesaid action prevents the engine from driving the starter. This is actually an important step because this particular kind of back drive would enable the starter to spin so fast that it will fly apart. Unless adjustments were done, the sprag clutch arrangement would preclude using the starter as a generator if it was used in the hybrid scheme mentioned earlier. Normally a regular starter motor is intended for intermittent utilization which will prevent it being utilized as a generator.
The electrical parts are made to be able to function for roughly 30 seconds to stop overheating. Overheating is caused by a slow dissipation of heat is because of ohmic losses. The electrical parts are designed to save weight and cost. This is actually the reason most owner's handbooks used for vehicles suggest the driver to pause for at least 10 seconds right after each and every 10 or 15 seconds of cranking the engine, whenever trying to start an engine that does not turn over immediately.
In the early 1960s, this overrunning-clutch pinion arrangement was phased onto the market. Prior to that time, a Bendix drive was used. The Bendix system operates by placing the starter drive pinion on a helically cut driveshaft. When the starter motor starts turning, the inertia of the drive pinion assembly enables it to ride forward on the helix, hence engaging with the ring gear. As soon as the engine starts, the backdrive caused from the ring gear enables the pinion to surpass the rotating speed of the starter. At this instant, the drive pinion is forced back down the helical shaft and thus out of mesh with the ring gear.
The development of Bendix drive was made in the 1930's with the overrunning-clutch design known as the Bendix Folo-Thru drive, developed and introduced in the 1960s. The Folo-Thru drive has a latching mechanism together with a set of flyweights inside the body of the drive unit. This was an enhancement because the average Bendix drive utilized to be able to disengage from the ring as soon as the engine fired, although it did not stay functioning.
As soon as the starter motor is engaged and begins turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. As soon as the drive unit is spun at a speed higher than what is attained by the starter motor itself, like for instance it is backdriven by the running engine, and next the flyweights pull outward in a radial manner. This releases the latch and permits the overdriven drive unit to become spun out of engagement, hence unwanted starter disengagement can be avoided prior to a successful engine start.
